The original bulb that came in the original CHEXX game and the Super CHEXX game had one major issue—it produced a large amount of heat, that could cause plastic warping or other heat related issues.  The cover of my bubble hockey light was warped from heat.  If you read below, I’ll go through the steps you need to upgrade your bubble hockey lighting.

I had seen some suggestions in online forums to try doing some LED lighting in the game instead, now that LED’s were more affordable.  Some people had used LED strips (which seemed a little hacky although effective) and others had used LED bulbs, almost all of which were no longer available since the posts were older.

I decided to go and try and figure out some good bulbs on my own, keeping in mind the wattage for the original bulb to make sure that I didn’t overdraw the circuit.  The bulbs I found were these:

new led bulbs from amazon

I ordered the bulbs from Amazon through this affliate link:

Amazon LED bulb link

To install the bulbs, I had lift up the dome so I could see the underside of the scoreboard.  From there, you can see the four screws that need to be unscrewed to access the bulbs.

bubble hockey underneath scoreboard

After removing the screws, inserting the bulbs is pretty easy.  Here is a picture after they are already installed.

led bulbs installed in bubble hockey

This is what the old bulbs look like (1156 bulbs):

old bubble hockey 1156 bulbs

It ended working great.  Here’s the before picture:

bubble hockey old lamp

And here’s the after picture:

bubble hockey after LED picture

If you look at the pictures, the biggest difference is in how much light is out by the edges of the playfield, the center is largely the same.  Obviously the biggest advantage is one you can’t even see, the amount of heat being way less than before.

If you have other bubble hockey questions, check out my guide here:

Bubble Hockey Guide

Or look for other bubble hockey articles I’ll be posting in the coming months.
